V.R-3SW

Bookmark and Share
http://wowslider.net/ by WOWSlider.com v8.7
  • Potentiometer V.R-3SW is a panel setting device for a maximum wattage ratting upto 3 watt with a micro NC / NO switch with maximum current rating upto 5A @ 230VAC
  • V.R-3SW has been specifically designed to have longer life, No discontinuity and smooth movement of shaft along with a additional feature to completely isolate the system from voltage entering the system.
  • It has a feasibility to customize in several ways. Such as shaft modification, lug terminal arrangement, a vast range of ohmic value from 10 ohms to 100k ohms.
  • The capability of the company to produce a vast range of ohmic value in potentiometer is a USP on its own.
  • The Product can be made to Ingress protection upto IP65 and above on request.
  • V.R-3SW has several other variants with model number V.R-3 (panel set potetniometer), V.R-3G (Ganged Potentiometer), V.R-3S (Endless Potentiometer), V.R-3CT (4 wire potentiometer),



Mounting

For best performance of V.R-3SW below points needs to be taken into consideration.
1) The hole in the panel should not be more than 9.5mm.
2) 2) V.R-3SW should be mounted with Star washer given along with the product and perpendicularity between the panel and axis of potentiometer should be maintained.
3) For applications with extreme vibration please use lock nut assembly which is being supplied on the demand.

Electrical Specification.

Resistance Range 10 ohms to 100kOhms
Total resistance tolerance +/-10% (Standard) +/- 5% or +/-2% available on request
End Resistance 2 ohm or 0.1% which ever is greater
Temperature coefficient of resistance Maximum 130 ppm / deg. C
Power rating 3 watt @ 40 deg C
Maximum wiper current Based on power rating of potentiometer and applied voltage
Maximum working voltage 250Vdc
Insulation Resistance 200 Mohms @ 500VdC
Voltage Proof 1500Vdc for 1 min @ sea Level
Effective Electrical angle 226 +/- 15deg
Temperature range upto 70 deg C
Standard resistance range 10, 25, 50, 100, 250, 500, 1K, 2K, 2K5, 3K, 5K, 10K, 15K, 20K, 25K, 50K, 100K. (Any other values on request)

Ordering Information

V.R-3SW - Resistance Value - Shaft length - Any specific Info.V.R-3SW-10k Ohms-25mm

Mechanical Drawing

    Operating Sequence
  • From 0 to 54 degree the resistance between pin 1 and 2 and pin 3 and 2 will be infinite and switch will be in Normally close mode
  • From 54 to 285 deg resistance between bin 1 and 2 will slowly increase from from 0 ohms to full range while the resistance between pin 3 and 2 will decrease from full range to 0 ohms.
Housing Material ROHS complaint Material
Mechanical Angle of rotation 285deg +/- 15 deg
Starting Torque
End Stop Torque.
Bush Material Brass
Spindle Material Brass (standard). S.S on request.
Rotational Life expectancy 50,000 cycles.
